Detailed InformationModelYS140M-36YS145M-36YS150M-36YS155M-36YS160M-36YS165M-36YS170M-36Rated Maximum Power at STC140W145W150W155W160W165W 170wMaximum Power Voltage (Vmp)17.99V 18.06V 1
DC 1000V(IEC) / 1500V(IEC) / 600V(UL)
Model YS140M-36 YS145M-36 YS150M-36 YS155M-36 YS160M-36 YS165M-36 YS170M-36 Rated Maximum Power at STC 140W 145W 150W 155W 160W 165W 170w Maximum Power Voltage (Vmp) 17.99V 18.06V 18.11V 18.17V 18.22V 18.26V 18.28V Maximum Power Current (Imp) 7.79A 8.04A 8.28A 8.53A 8.79A 9.06A 9.32A Open Circuit Voltage ( Voc) 22.32V 22.39V 22.48V 22.54V 22.59V 22.66V 22.73V Short Circuit Current (Isc) 8.44A 8.63A 8.79A 8.88A 9.32A 9.57A 9.82A Module Efficiency 14.12% 14.62% 15.13% 15.63% 16.14% 16.64% 17.15% Power Tolerance 0~+3% 0~+3% 0~+3% 0~+3% 0~+3% 0~+3% 0~+3% STC: Irradiance 1000W/m², Module Temperature 25°c, Air Mass 1.5 Mechanical Parameters Cell Type Mono-crystalline 156x156mm (6inch) No. of Cells 36 (4x9) Dimension 1480x670x30/35mm Glass 3.2mm, High Transmission, Low Iron, Tempered Glass Junction Box IP65&IP67 Rated Output Cable Section Size: 2.5mm² , Length: 600mm Frame Anodized Aluminum Alloy No. of Bypass Diodes 2 Connector MC4 Compatible Working Conditions Maximum System Voltage Operating Temperature -40°c~+85°c Maximum Series Fuse 15A NOCT 45±2°c Application Class Class A Temperature Coefficient Temperature Coefficient of Pmax -0.40%/°c Temperature Coefficient of Voc -0.30%/°c Temperature Coefficient of Isc +0.06%/°c
